Synteny of FGFR Paralogon

The conservation of gene synteny on different chromosomal regions entails the functional significance of those genes. For instance, the co-expression of neighboring genes is mediated by high order structural organization of chromosomes, which brings together the far off genomic regions in close proximity in order to be expressed together in a coordinated manner (Parveen et al., 2013). Similarly, the gene regulatory elements spread across long regions impose critical constraint on genomic architecture and are known to have maintained exceptionally long syntenic blocks both within and across species (Meaburn and Misteli 2007).

Gene families with threefold or fourfold representation in the proposed paralogy regions on human chromosomes 4, 5, 8 and 10 (FGFR-bearing chromosomes) were identified by scanning the human genome sequence maps available at the Ensembl and UCSC genome browsers (Flicek et al., 2011; Fujita et al., 2011; Hubbard et al., 2002). A total of 80 gene families with at least three fold representations on these chromosomes were identified. Schematic synteny map of these 80 multigene families was manually sketched to depict their relative positioning on respective chromosomal locations. Members of these gene families also have representations on non-FGFR bearing chromosomes. Such members are not drawn on synteny map (Figure 1).

Figure 1: Gene families with members on at least three of the human FGFR-bearing chromosomes 4, 5, 8, and 10.
